Interactive · 2 questions

We define a function ff to be periodic if there exists a TT such that

f(t+T)=f(t)(for all t)f(t+T) = f(t) \quad \quad (\text{for all t})

Which is to say that, the function repeats itself after a fixed time interval.

Before proceeding think of an example of such a function.

Okay, here is the most popular periodic function sin⁡(x)\sin(x)

(Graph borrowed from Draw Plots guide)

Given that f(t+T)=f(t)(for all t)f(t+T) = f(t) \quad \quad (\text{for all t})

we define the period of the function to be TT.

Consider the rotation of the earth about its axis. What is the period of this rotation?

Choose one answer

Illustrated · 1 min

A function is periodic if it repeats a set of outputs after a certain T. In mathematical terms this means that a function, f(x)f(x), is periodic if it satisfies f(x+T)=f(x)f(x+T) = f(x).

There are 3 main parts of a periodic function,f(x)=a∗f(x+T)f(x) = a*f(x+T) are period, frequency, and amplitude:

The period is how long the function takes to return to the same set of outputs. In the periodic function shown above, the period is TT.

The frequency is how many times the function oscillates or goes through a period in a certain amount of time(usually 1 second). This is equal to 1T\frac{1}{T}.

The amplitude is max amount the function deviates from the mid-line or average. This is always a positive number.. In the function shown above, the amplitude is ∣a∣|a|.

The most common periodic functions are sinusoids(functions that are composed of sinsin or coscos. Graph of y=sin(x)(inblue)andy=sin(x)(in blue) andy=cos(x)(ingreen):(in green):

The period and frequency of both functions are 2∗π2*\pi and 12∗π\frac{1}{2*\pi}. The amplitude are both 11.

In a sinusoid function, f(x)=a∗sin(bx)f(x)=a*sin(bx), the period is 2∗π∣b∣\frac{2*\pi}{|b|}. The frequency is ∣b∣2∗π\frac{|b|}{2*\pi} and the amplitude is aa.
